Topas Fluoroscent
Description
Topas luminaires are the most suitable lighting solution whenever soft lights are requested. They have an extremely consistent light distribution over a large beam angle. Depending on the used fluorescent tubes, they can be mixed with halogen or daylight spot lights. Because of the high light-output efficiency, they generate very low heat. The newly developed electronics allow a flicker-free operation with a linear dimming range of 10% to 100%. The dimming can be controlled manually by a local dimmer or any DMX-capable lighting control device. The design of the housing and the arrangement of the tubes guarantee best cooling conditions, a very important premise for constant color temperature of the light. The selected DMX channel is shown on a big display. Every luminaire is equipped with mains IN and OUT and DMX IN and OUT sockets. This allows a daisy chain of several luminaires. A large range of accessories ensures easy and flexible integration in any studio.
Technical Specifications
| Power supply | 230V / 50-60 Hz |
|---|---|
| Mains IN | PowerCon |
| Mains OUT for daisy chain | PowerCon |
| Mains fuse | 10 A |
| Mains cable | 2m with Schuko plug |
| Dimming range | 10 – 100% |
| Control | DMX 512/ 0 – 10V (option T-DIM2) |
| DMX IN | XLR 5p |
| DMX OUT for daisy chain | XLR 5p |
| Tube socket | 2G11 |
| Operating temperature | 0 to +40 °C |
| Air humidity | 0-95 % |
Photometric Data
| Distance | Topas 110 with barndoor | Topas 220 with barndoor | Topas 330 with barndoor | Topas 440 with barndoor | Topas 660 with barndoor | |||||
|---|---|---|---|---|---|---|---|---|---|---|
| black reflective | black reflective | black reflective | black reflective | black reflective | black reflective | black reflective | black reflective | black reflective | black reflective | |
| 1m | 1760 | 2370 | 3300 | 4370 | 6012 | 7816 | – | – | – | – |
| 2m | 510 | 690 | 905 | 1220 | 1275 | 1715 | 1640 | 2210 | 2580 | 3480 |
| 3m | 255 | 305 | 465 | 620 | 675 | 885 | 940 | 1270 | 1315 | 1770 |
| 4m | – | – | 280 | 375 | 410 | 538 | 540 | 730 | 795 | 1070 |
| 5m | – | – | – | – | 195 | 256 | 370 | 500 | 545 | 730 |
Versions
| Versions/Order code | Topas 110 | Topas 220 | Topas 330 | Topas 440 | Topas 660 | ||||
|---|---|---|---|---|---|---|---|---|---|
| Standard (manual yoke) | T113T | T223T | T333T | T443T | T663T | ||||
| Studio (pole operated) | T113TM | T223TM | T333TM | T443TM | T663TM | ||||
| Location (ball head) | T113TL | T223TL | T333TL | T443TL | T663TL | ||||
| Weight | |||||||||
| Standard (manual yoke) | |||||||||
| 5 | 0 kg | 6 | 1 kg | 7 | 7 kg | 9 | 2 kg | 12 | 2 kg |
| Studio (pole operated) | |||||||||
| 6 | 1kg | 7 | 2 kg | 8 | 8 kg | 10 | 3 kg | 13 | 3 kg |
| Location (ball head) | |||||||||
| 5 | 0kg | 6 | 1 kg | 7 | 7 kg | 9 | 2 kg | 12 | 2 kg |
| Number of tubes (55W) | 2 | 4 | 6 | 8 | 12 |
Components & Accessories
| Accessories | Topas 110 | Topas 220 | Topas 330 | Topas 440 | Topas 660 |
|---|---|---|---|---|---|
| Gelframe | TFR110 | TFR220 | TFR330 | TFR440 | TFR660 |
| 4-leaf barndoor black | TDB110 | TDB220 | TDB330 | TDB440 | TDB660 |
| 4-leaf barndoor reflective | TDR110 | TDR220 | TDR330 | TDR440 | TDR660 |
| Egg crate | TETT10 | TET220 | TET330 | TET440 | TET660 |
| Ball head | TBIH16 | TBIH28 | TBIH28 | TBIH28 | TBIH28 |
| Manual yoke | TMSI23 | TMSI23 | TMSI23 | TMS46 | TMS46 |
| Pole operated yoke | TPOI23 | TPOI23 | TPOI23 | TPO46 | TPO46 |
| Tube 3200 K (tungsten) | L5532C | L5532C | L5532C | L5532C | L5532C |
| Tube 5600 K (daylight) | L5556C | L5556C | L5556C | L5556C | L5556C |
| Local dimmer | T-DIM2 | T-DIM2 | T-DIM2 | T-DIM2 | T-DIM2 |
| PowerCon connecting cable 2,5m | PCON-25 | PCON-25 | PCON-25 | PCON-25 | PCON-25 |
| PowerCon connecting cable 5m | PCON-50 | PCON-50 | PCON-50 | PCON-50 | PCON-50 |
| DMX connecting cable 2,5m | DMX-25 | DMX-25 | DMX-25 | DMX-25 | DMX-25 |
| DMX connecting cable 5m | DMX-50 | DMX-50 | DMX-50 | DMX-50 | DMX-50 |
Catalog
- Service life ca. 50.000 hours
- High power efficiency by using latest LED technology
- Color temp. 3200K, 5600K or Tunable white 2800K-6500K
- Robust but lightweight aluminum housing with built-in power supply
- Display for information about operating status, DMX manual/auto, DMX address, dim factor in % precise dim, temperature, fan mode and dimming curves
- CRI >98 and TLCI > 98
- Protection against overheating with low noise fan
- Consistent light distribution over wide beam angle and 130mm lens
- Accessories compatible with Director Halogen lights Director Halogen luminaires (650W)
- see also: DL8 DL17 DL20 DL30
